NEW QUESTION 65
Is this a way that Virtual Switching Extension (VSX) differs from Virtual Switching Framework (VSF)?
Solution: VSX permits admins to select which features to synchronize between members while VSF requires manual configuration of Identical features on each member of the VSF fabric.

NEW QUESTION 66
The architect designs a spine and leaf network for a single data center that will use multiple leaf switches as Virtual Tunnel End Points (VTEP). The architect needs to select the type of Integrated Routing & Bridging (IRB) for the solution.
Is this statement about the IRB type true?
Solution: In the Asymmetric IRB egress VTEPs bridge the traffic to the destination networks.

NEW QUESTION 67
Refer to the exhibit.

which shows the topology tot an Ethernet Ring Protection Switching (ERPS) solution.
Is this a valid design for the control and protected VLANs on the VSX fabric 1 switches?
Solution: Ring 1, Instance 1:
control VLAN: 51 protected VLANs: 51-100 Ring 1, Instance 2:
control VLAN: 51 protected VLANs: 101-150 Ring 2, Instance 1: control VLAN: 181 protected VLANs: 181-200 Ring 2, Instance 2: control VLAN: 181 protected VLANs: 201-220

NEW QUESTION 68
Refer to the exhibit.

Switch-1 and Switch-2 ate ArubaOS-CX switches that implement VXLAN WITHOUT Ethernet VPN (EVPN). Switch-2 uses the same VNI-to-VLAN mappings as Switch-1. Is this how the specified servers communicate?
Solution: The first time that Server I communicates with Server 3, It sends an ARP request to resolve Server 3’s MAC address.

NEW QUESTION 69
Refer to the exhibit. The company wants AtubaOS-CX switches to provide VXLAN services for several VMs and servers, as shown in the exhibit. Hypervisors will not run VXLAN for this solution. Is this part of a valid configuration to meet the requirements?

Solution: Attach VNIs 5010 and 5020 to interface 1/1/3 on Switch-2.

NEW QUESTION 70
Is this a use case for implementing Enhanced Transmission Selection (ETS) on an ArubaOS-CX switch?
Solution: ensures a minimum bandwidth guarantee between two endpoints traffic with various 802.1 p values.

NEW QUESTION 71
Is this a way that a data center technology can help meet requirements for multi-tenancy?
Solution: Virtual Extensible LAN (VXLAN) enables multiple isolated Layer 3 domains, each with its own routing table, to share a physical network.

NEW QUESTION 72
You enter this command on an ArubaOS-CX switch:
Switch# show erps status ring 1
Is this what the specified status means?
Solution: The status is Protection, which means that the ring is up and fully connected with the RPL port blocked.

NEW QUESTION 73
Is this a guideline for establishing a Virtual Switching Extension (VSX) Inter-Switch Link (ISL) between two ArubaOS-CX switches?
Solution: Reserve the ISL for control plane traffic only.

NEW QUESTION 74
Does this correctly describe how Network Analytics Engine (NAE) agents work?
Solution: Agents write data to the switch’s current state database.

NEW QUESTION 75
Is this a use case for deploying Ethernet Ring Protection Switching (ERPS)?
Solution: connecting multiple data centers at Layer 2 while minimizing the number of dark fiber connections required

NEW QUESTION 76
A data center has a three-tier topology with ArubaOS-CX switches at each layer, is this a use case for implementing Virtual Switching Extension (VSX) at the core?
Solution: The aggregation layer operates at Layer 2 only, and the core provides Layer 2 and Layer 3 functions.

NEW QUESTION 77
Refer to the exhibits.


Is this how the switch-1 handles the traffic?
Solution: A broadcast arrives in VLAN 10 on Switch-1. Switch 1 forwards the frame on all interfaces assigned to VLAN10. except the incoming interface. It replicates the broadcast, encapsulates each broadcast with VXLAN. and sends the VXLAN traffic to 192.168.1.2 and 192.168.1.3.

NEW QUESTION 78
Can you attach this type of ArubaOS-CX interface to a VRF?
Solution: A Layer 3 VLAN interface

NEW QUESTION 79
Is this something that NetEdit 2.0 does after it discovers a switch?
Solution: It enables SNMP on the switch, if disabled.

NEW QUESTION 80
You are using NetEdit to manage AruDaOS-CX switches. You want to deploy a standard config to the switches, but need the config to include a few device-specific settings such as hostname and IP address.
Is this what you should do?
Solution: omit the device-specific settings from the configuration plan and include them in command scripts instead.

NEW QUESTION 81
Does this correctly describe the ArubaOS-CX architecture?
Solution: The AtubaOS-CX software is based on the ArubaOS-Switch software and adds data center features.

NEW QUESTION 82
Is this part of a valid strategy for load sharing traffic across the links in an Ethernet Ring Protection Switching (ERPS) solution?
Solution: Create two ERPS instances for the ring and assign different VLANs and different ring protection links (RPL) to each instance.

NEW QUESTION 83
Does this correctly describe routing information advertised by a VXLAN Tunnel Endpoint (VTEP) that uses EVPN?
Solution: IMET routes advertise the MAC addresses that the VTEP has learned locally in a VXLAN.

NEW QUESTION 84
An ArubaOS-CX is ssmq DCBX on Interface 1/1/1. You enter this command:
show dcbx interface 1/1/1
Is this where you can see whether the connected converged network adapter (CNA) has accepted the application priorities advertised with DCBX?
Solution: in the Application Priority Map Local advertisement section

NEW QUESTION 85
Is this a use case for disabling split-recovery mode on ArubaOS-CX switches in a Virtual Switching Extension (VSX) fabric?
Solution: In situations in which the primary switch fails and then reboots, you want to make the primary switch take over again as the primary switch.

NEW QUESTION 86
Is this a guideline for establishing a Virtual Switching Extension (V5X) Inter-Switch Link (ISL) between two ArubaOS-CX switches?
Solution: Use the same speed on every link In the ISL.

NEW QUESTION 87
You are configuring Ethernet Ring Protection Switching (ERPS) on an ArubaOS-CX switch. Is this a guideline for configuring timers?
Solution: The guard interval is set in units of seconds and is used to prevent frequent topology changes due to a link going up and down.

NEW QUESTION 88
Is this a guideline for establishing a Virtual Switching Extension (VSX) Inter-Switch Link (ISL) between two ArubaOS-CX switches?
Solution: Use a link aggregation with multiple 40GbE links or multiple 100GbE links.

NEW QUESTION 89
Refer to the exhibit. You are adding a VLAN 30, subnet 10.0.30.0/24 to the network shown in the exhibit. (This network is simplified to just the relevant switches for this item.) This subnet belongs in VRF A, and you have added a Layer 3 VLAN 30 interface attached to this VRF on Switch-1.
You want to make the services in this VLAN available to devices in 10.1.20.0/24 in VRF B.

Is this part of a valid setup for meeting these requirements?
Solution: Add a route with this command: ip route 10.1.20.0/24 vlan20 vrf A
